ISTA/P CANNOT WORK WITH BMW F/G/I SERIES SINCE ISTA/P 3.62.0?

Release Notes ISTA-P_3.63.3_4.09.1x:

F, G and I series (will be switched off gradually from ISTA/P 3.62.0 on)

(that means that no partial programming for those cars.)

In detail…

ISTA/P – Note about switching off F, G, I series group

Description:

With the launch of ISTA 4, the functionality for programming the F, G, I series has been integrated in ISTA. From ISTA/P version 3.62.0 on (end of June 2017), the programming of the F, G, I series with ISTA/P will be gradually switched off.

Model series affected:

F, G, I series vehicles. ·

Series F056 can no longer be dealt with as of ISTA/P 3.62.1. ·

Series I001, F001, F025, S15A, S15C can no longer be dealt with as of ISTA/P 3.63.0.

Action:

Install ISTA 4 with vehicle software service data package. Use ISTA 4 for programming the F, G and I series.

Affected application:

ISTA/P

Note: E series can still be dealt with using ISTA/P.

Test: 2017 G12 in ISTA-P 3.65

Tried to program headlight module for 2017 G12 in ISTA P 3.65, but it cannot be done.

In order to program the module, the professional open ista d and i program the whole car.

201809-bmw-icom-ISTA-P-3.65

Good solution to program F/G/I series:

Use ESYS and skip the risk of bricking car modules with ISTA-P

To flash whole car, You can use esys to flash whole car with just one click

Or

Use ISTA-P before version 06.2017

2017.5 BMW ISTA-D 4.05.20 ISTA-P 3.61.4.002
2017.3 BMW ISTA-D 4.04.12 ISTA-P 3.60.2.001

How to TRANSFORMS 4C CHIP INTO 4D CHIP via VVDI KEY TOOL

How to: transform transponder 4C chip into 4D chip with Xhorse VVDI Key tool

This is the 4D chip to be transformed

vvdi-keytool-4d-to4c-chip-1

Go to VVDI Keytool special functions

vvdi-keytool-4d-to4c-chip-2

4D to 4C

vvdi-keytool-4d-to4c-chip-3

Put the chip into the coil

vvdi-keytool-4d-to4c-chip-4

VVDI keytool successfully generates 4D chip into 4C

vvdi-keytool-4d-to4c-chip-5

Test if it’s the 4C or not

Go to VVDI keytool clone transponder

vvdi-keytool-4d-to4c-chip-6

Detection

vvdi-keytool-4d-to4c-chip-7

vvdi-keytool-4d-to4c-chip-8

Tested! It’s Toyota 4C chip

vvdi-keytool-4d-to4c-chip-9

Job’s done!

Annonce initiale de mise à jour OBSTAR de septembre 2018

Annonce initiale de mise à jour OBSTAR de septembre 2018

IMMO
BMW
Upgraded SWFL support version to ISTAP65
Baihc
1. Optimized the menu structure
2. Optimized Baihc Shenbao D20 key erase failure problem
VW/Audi/Skoda/Seat
Upgraded Audi TT EEPROM data reading and key programming function
Peugeot/Citroen/DS

1. Increased BOSCH ME7.4.4/ME7.4.5 pin code reading function
2. Increased BOSCH EDC15C2 pin code reading function(doesn’t support  simplified or traditional Chinese)
Opel
Increased DELPHI 70F3379+93C86 pin code reading function
Holden
Increased DELPHI 70F3379+93C86 pin code reading function
GM
Increased DELPHI 70F3379+93C86 pin code reading functi

Cluster Calibration
GM
Optimized 2015-Sierra/Tahoe security algorithm
Audi
Upgraded Audi TT/A3 cluster calibration function
Porsche
Optimized Panamera/Cayenne 2010-cluster calibration
ECU Clone
Peugeot
1. New increased ME7.4.5、ME7.4.4、EDC15C2
2. EDC15C2 distinguish 1X Connect and 3X Connect type
3. Distinguish the prompt ‘to ensure the security of data, pls don’t use Bluetooth for testing’ according to device model
BOSCH ECU Clone Software
1. Increased BOSCH ME7.4.4 EEPROM/FLASH reading and writing function
2. Increased BOSCH ME7.4.5 EEPROM/FLASH reading and writing function
3. Increased BOSCH EDC15C2 EEPROM/FLASH reading and writing function
BMW Programming Software
1. Optimized 6HP reset function
2. Upgraded 8HP programming SWFL support version to ISTAP65
Oil/Service Reset
Updated the Portuguese text
TPS Reset Software
Updated the Portuguese text
Battery Matching
New increased as follow:
BYD: K9A
FAW Audi
Dongfeng Citroen:C4L(B7)/DS5 Hybird 4
Geely: Vision X6/Emgrand GS/Emgrand GL/Borui
GAC Trumpchi: GS4/GA6/GA5 1.6T/1.8T/2.0T DCVVT/GS5/GS5(Super)
GWM: Changcheng C30/Changcheng C30EV/Hover H2s/Hover H7/H7L/VV7/P8
Optimized Audi A6 battery matching failure problem
ABS Software
Updated the Portuguese text
H100 Display Program Software
Increased configuration
Tablet Display Program Software
1. Increased UIList customized listing function
2. Revised the prompt of VCI disconnected during algorithm networking verificati
3. Increased carlist, software introduction, upgrade announcement and “help”function button
    in the version information before entering into diagnosis information
APK Software
1. Optimized the UI design
2. Optimized the typesetting of user manual
3. Replaced the‘ok’ and ‘cancel’ button with Enter and Esc
4. Remind the update of user manual and FAQ with red dot
5. Revised the log in/out logic
6. Increased the customized list
7. New increased the version display
Throttle Matching Software
New increased as follow:
Shuanghuan
Youngmanlotus
Jianghuai: type 6/type 7
Dongfeng Fengshen: type2/ type3/ type4
BYD: S7(2017)Tang/F0/Type 3 (BOSCH)/Tang(2017)
Geely: Type 2 (Delphi)/Type 3 (Lianchuang)/Vision
Zotye: T600_COUPE/T600 Sports/Damy X7/T600/T200/2008/5008 models
Changan Ford:
(all 2005 models)Escape(Asia)/Tribute/Maverick(Europe)/MarinerEdge/Escape(Asia)/Mariner Hybrid
Kuga/Fiesta MY2013/Focus Cabriolet/Focus(Focus VIN = LEA/LVS/AFA/PE1/FFJ)/Fusion
Changan:
CS35(S101)/CS75(S301)/Raeton(CD101)/Eado XT(C202)/Eado(C201)/Lingxuan (V301)/Alsvin/AlsvinV3(B501)/CX20-GA13
CX30/Benni/Benni MINI/Zhixiang/Jiexun/CV7/CV9/A800/A600(H16EB-6AT)/A600(DAM15-5MT)/X70A/Honor/Honor S
Changan Star/New Changan Star/CM8/Xingka/Ruixing/Zunxing

WHERE TO BUY AUTO DIAGNOSTIC TOOLS WITH TAX FREE?

Auto scan tools with Tax or Duty FREE, where to:

http://www.eobdii.fr/producttags/ship-from-eu.html

Items here are shipped from the warehouse in UK.

Save a lot! You will pay for the items you want only, not for the consumption.

Fast delivery! The item is shipped from UK, benefiting a lot to you guys in Europe!

Tax-FREE items:

V178 Renault CAN Clip Diagnostic Interface

【Livraison UE sans taxe】Nouveau ACTIA Multi-Diag 2016 MULLER Multidiag ACCESS XS Valise Diagnostic No Need Activation

【Livraison UE sans taxe】Version Française Launch X431 V 8 inch Lenovo Tablet Wifi/Bluetooth Système Mise à Jour En Ligne 2 Ans

【Livraison UE sans taxe】Version française AUTEL MaxiDAS DS808 KIT Tablet Diagnostic Tool Full Set soutien mettre à jour

Customer can click the link for more informations



Disque dur pour Super MB STAR est maintenant mis à jour à V2018.9

Disque dur pour Super MB STAR est maintenant mis à jour à V2018.9

Newly Added Special Function

1. Erase SCR ADBLUE fault code (in MR) with correct New FDOK XN
2. Nox Torque Limit Setting (in FR_CPC0) with correct New FDOK XT
3. Special Function Password Free for Transporter
4. Password Free & OFFLINE key teach-in  program key transponder key Smart SAM451 &ETACS454 2016-12 UP
5. Add dev data and read codingstring in ESP 454
6. Add DevData&DeData in cu adaptation SAM451+DevData&ExtraCoding in cu adaptation ESP451
7. SMART SAM 450 & 452 Extra Functions Writing VIN & Development Status (inside control unit adaptation)
8. W204 available in DAS
9. Special Function Password Free (Cars, VANs, Sprtiners, etc.)
10. TRANSMISSION or GETRIEBE – EGS2 Diagnosis Routine password free
11. Audio Video Navigation and telematics – add Dev menu in COMAND APS
12. TRANSMISSION or GETRIEBE – EGS1 Special Function password free
13. Audio Video Navigation and telematics – HU Exchange Audio 50 to COMAND password free
14. Develop mode in full vehicle list
15. Online SCN Coding Free for 10 times (Need provide Super MB STAR S/N.)
16. Offline Coding / offline SCN coding available.



http://www.eobdii.fr/hard-disk-for-super-mb-star-dell-d630-format-937.html

Fly EasyMaker Honda Key Programmer Operation Instructions

Honda Key Programmer Operation Instructions

1. For transponder key.

A. Switch to “IMMO”, and prepare all keys to register.

B. Turn ignition ON to position II(Instrument panel light on but engine OFF), connect programmer to OBDII socket

C. The buzzer periodically short beep with “Di”, Turn ignition OFF.

D. The buzzer periodically short beep with “Di, Di, Di”, turn ignition on without changing key.

E. The buzzer long beep once “Di—“, key registration begins.

F. The buzzer periodically short beep with “Di”, Turn ignition OFF.

G. The buzzer periodically short beep with “Di, Di”, Change another key and turn ignition ON

H. Repeat step F,G, register more up to 6 keys.

I. For last key: First turn ignition ON/OFF following above instructions. When the buzzer periodically short beep with “Di Di”, turn on ignition WITHOUT changing key. Then the buzzer periodically short beep with “Di”, DO NOT turn off ignition and keep ignition on for more than 20 seconds.

J. The buzzer long beep once “Di—“, key registration finished.

K. The buzzer periodically long beep with “Di—“, start to learn remote function. Learning remote function instruction: close all doors, press and release lock/unlock button on key in 4 seconds until door locks lock/unlock. Then learn next remote.(Some cars do not need remote learning, and no buzzer beep tips for learning remote)

L. Turn ignition OFF. Pull out programmer from OBDII. Try to start engine with every key.

2. For smart key.

A. Switch to “SMRT”, and prepare all smart cards to register. Only 1 card in car, and the others out of car.

B. Push one-push-start button, or use ignition key in card, turn ignition ON(Instrument panel light on but engine OFF). If all cards lost and can’t turn ignition on, press and hold one-push-start button. Connect programmer to OBDII socket.

C. The buzzer periodically short beep with “Di”, turn ignition OFF

D. The buzzer periodically short beep with “Di, Di, Di “, turn ignition ON.

E. The buzzer long beep once “Di—“, card registration begins.

F. The buzzer periodically short beep with “Di”, take card out of car.

G. The buzzer periodically short beep with “Di, Di”, take another card in car.

H. Repeat step F,G, register more up to 6 cards

I. For last card: First take card in car following instruction. When the buzzer periodically short beep with “Di”, DO NOT take card out of car and keep card in car for more than 100 seconds.

J. The buzzer long beep once “Di—“, cards registration finished.

K. Turn ignition OFF. Pull out programmer. Try to start engine with every card.

ICOM NEXT ESYS FITTED & CODED NEW FRM3: SOLVED!

Solved! ICOM Next Esys fitted & coded new FRM3. Everything is working.

Issue:

Fitted and coded a brand new FRM3 everything is working except power windows, I cannot initialise them because the FRM has a Windows Regulator over temperature fault stored so has shutdown power to the windows.
Got issues with both front windows, car does not have rears that open

But windows were working with previous frm

I cannot clear this fault at all with ISTA+
I am using latest psdz and have FA coded (no mods) several times to no avail.

Car: 2013 F13
Tool: ICOM Next

Jararak advice:

try to recode it one more time with null file (regarding VO)

maybe try to power off transport mode

Result:

Have FA coded several times now, I did do a delete transport mode after fitting, but if it was in transport mode other things would not work

KKKKK advice:

You only need to initialize the windows with ista+ ! That’s all after coding.

Result:

Can’t do that Ista+ does nothing because of over temperature fault code

Now solved!!!
Flashed latest software and re-coded all errors now gone and windows initialised.

Flashed with latest software using Esys and Icom Next

BMW BATTERY REGISTRATION/PROGRAMMING WITH ICOM CABLE

Programming and Registering are 2 different things. They use totally different equipment.
So I needed a new battery because my old one was holding an 11.5v charge when the car was off. I ordered a Braille no weight, 21lb battery from HP Autowerks with their custom battery tray. I had a shipping timing issue and Harold made sure it got to me before I went away.

So I come back from vacation and look for a good indy to install my new battery. I found Pinnancle Motor Werks in Stirling, NJ so I went there to get my battery installed/registered.

They have an Autologic for those wondering.

Anyway so we go through the menus to register the battery and since the Braille is an AGM battery, I need to program my car so it charges the battery correctly.

SO if you’re replacing your battery with an AGM and you have a lead acid battery, you NEED to program the correct type! Registering and programming are 2 different procedures.

However, the Autologic device had only the following options: 90Ah AGM, 90Ah, 80Ah AGM, 80Ah, 70Ah AGM, 70Ah, 55Ah, and 46Ah. I think that was all of them.

The Braille I bought has a 31Ah rating….what to do?

Basically my indy didn’t want to be held liable for damages later incurred….understandable. So I told the shop to program my car as a 70Ah AGM, the lowest Ah AGM available on my car. I was concerned about my car being programmed to charge an AGM, not a lead acid.

So we’ll see if my battery holds up. I was mainly concerned that my car was programmed to charge an AGM. The Ah rating will be something I will monitor over the life of the battery.

So things I learned from this: (For those of you who just want to read about registration and programming)

Battery Registration does 3 things:

1) Logs Mileage.
2) Tells the car a new battery is installed.
3) Not sure about this one but I think the car records the condition of the battery at 80% of the capacity…..as a reference point.

Now there is programming with ICOM A2 or ICOM Next…..which requires reintializing modules, mainly the CAS and FRM module.

Our cars have many different Ah ratings (90Ah, 80Ah, 70Ah) and types (AGM vs non-AGM). There are other parameters that differ as well but these are the main ones in programming. The main difference the computer needs to know is AGM or non-AGM. AGMs will charge differently. I guess different Ah ratings tell the car how long to charge the battery and how often to maintain it. Ah ratings are basically a reserve rating. A 1 amp draw on my 21lb Braille will last 31 hours before a recharge is needed.

Anyway, so the reason why I have decided this was a bad decison is because:

1) The CCAs on the Braille are 550A. Stock = 750A. This battery is fine for warmer climates but since I’m on the East Coast…..I’ll be needing a battery heater and a tender.
2) The Ah rating on the Braille is 31Ah. Stock = 90Ah. This is why I need a tender.

Those with a BT tool:

Reset Battery Adaptation and Battery Registration are redundant entries and send the same command. You can only use this option if you are replacing the battery with the SAME spec. Same Ah (capacity) and type (AGM vs non-AGM).

If you decide to install a battery with a different type or capacity you need to have the car programmed so it knows its capacity and type.

Here, AGM batteries will be explained:

GENERAL INFORMATION
In September 2002, the first VRLA batteries, better known as AGM batteries came into use.

VRLA means valve-regulated lead acid, or a lead battery with a pressure relief valve.

AGM stands for absorbent glass mat, or absorbent glass-fiber fleece.)

An AGM battery (90 Ah) is currently installed in the E46 with the M56 engine. Its use in other vehicle models will follow.

The continuously increasing energy requirements of modern vehicle electrical systems, demands ever more efficient battery solutions. A modern luxury vehicle has some (100) actuator motors that have to be provided with electrical current. In addition, there are safety, environmental and comfort features that are increasingly becoming part of the standard equipment such as ABS (anti-lock brake system), DSC (dynamic stability control), EPS (electric power steering), heated catalytic converter, electronically controlled suspension, air conditioning and navigation systems. Current consumption is considerable even when the vehicle is not in use.

AGM batteries are more expensive to produce, however this extra cost is offset by the following benefits:

Much longer service life

Improved starting reliability at low temperatures

Reliable starting of engines with high starting current requirements

100% maintenance-free

Low risk in the event of an accident (reduced environmental risk)

Service life of AGM batteries

(1) Available capacity [%]

(2) Distance [thousand km]

(3) AGM battery

(4) Lead-calcium battery

(5) 50% capacity line

Brief description of components

AGM batteries can be recognized by the black housing and the lack of the “magic eye”.

Index
Description
Index
Description

(1)
Positive grille with silver alloy
(6)
Set of positive plates

(2)
Positive plate
(7)
Set of negative plates

(3)
Negative grille
(8)
Block of plates

(4)
Negative plate
(9)
Block box with base strips

(5)
Separator made of glass-fiber fleece

Construction

AGM batteries differ from conventional lead-calcium batteries in the following points:

Larger plates:

Larger plates allow a power density some 25% greater.

Glass-fiber-fleece separators:

This enables a cycle consistency up to 3 times greater to be achieved.

This improves cold-starting ability, current consumption and service life.

Airtight housing with pressure relief valve:

The inspection plugs are sealed and cannot be opened.

Acid bound in grass-fiber fleece:

In contrast to conventional lead-calcium batteries, the sulfuric acid in a battery with fleece technology is not held as a liquid in the battery housing, but rather it is completely bound (100%) in the glass-fiber fleece (separators). This gives increased security against the acid escaping and thus reduces the environmental risk. For this reason, no acid can escape if the battery housing is damaged. In addition, the AGM battery is sealed to be airtight. This is possible because the gases are converted back into water by the permeability of the separators.

How it works

AGM batteries differ from conventional lead-calcium batteries in their environmental compatibility and their retention of gases during charging.

When a vehicle battery is charged, the electrolysis process emits the gases oxygen and hydrogen.

In a conventional lead-calcium battery, these two gases are released into the atmosphere.

In an AGM battery, the two gases are converted back into water: The oxygen created at the positive electrode during charging moves through the permeable glass-fiber fleece to the negative electrode, where it reacts with the hydrogen ions that are brought in with the electrolyte, to create water (oxygen cycle). In this manner, the gases, and thus the electrolyte, is not lost.

Only when the gas production is excessive, that is when too much pressure is generated (20 to 200 mbar), does the pressure-relief valve open, thereby allowing gas to escape while also preventing entry of atmospheric oxygen. Because the pressure in the battery is regulated by a valve, the AGM battery is also known as the VRLA battery (valve-regulated lead acid).

Service Instructions for AGM Batteries

When handling AGM batteries, certain special factors must be taken into consideration with regard to battery renewal and installation location.

Charging

Warning: Do not charge AGM batteries with 14.8 volts! Do not use rapid charging programs!

When charging batteries in the “stand alone” mode, the maximum charge voltage of 14.8 volts must not be exceeded. Even briefly charging an AGM battery with a charge voltage of more than 14.8 volts (voltages usually used in rapid charge programs) will damage the battery.

Installation Location

Warning: Do not install AGM batteries in the engine compartment!

Because of large temperature variations, AGM batteries must not be installed in the engine compartment. This would result in a significant reduction in the service life of the battery.

Do Not Open

Warning: Do not open AGM batteries

On no account should AGM batteries be opened, as oxygen from the atmosphere would cause the battery to lose its chemical balance and cause it to fail.

Battery Replacement

An AGM battery, when installed as original equipment, must always be replaced with an AGM battery.

In special cases, where a customer’s driving profile (e.g. short distance driving), results in a discharged battery, the AGM battery is a recommended replacement. Note that replacement batteries resulting from a customer’s driving profile cannot be claimed under warranty.
So as long as you replace your battery with the same spec (CA, CCA, Ah ratings, and type (AGM, non-AGM)), then you just need to register your battery.

If you change any specs you may need to program, then register the battery….especially when retrofitting an AGM.

I don’t think small differences in ratings will require programming, just registration. As long as the Ah rating and type are the same/similar values, then you should be good.

EDIT: I also forgot to mention that the battery I received was a bit smaller than the ones in the DIY guides here and on M3post. My power distribution block sat directly over the negative terminal opposed to next to it, like the ones in the DIY.

I had to configure it in a weird way. I’ll post up a picture later.

I did not want to remove the distribution block because it holds the main fuses for our cars and also I would need to cut, fuse, and terminate 4 or 5 wires, some being a pretty thick guage. I’m lazy….

FORD IDS 110 REVIEW: 2011 RANGER/MAZDA B SERIES/TROLLER 2.2L – DIAGNOSIS ALL OK

Ford IDS 110 install – I see this solution on internet as attacked file. Everyone can try and confirm the result. Hope it can help someone! Here is the released web I found:

How to install Ford IDS 109 software:

1- Install the ids 86 before changing the date to 1 07 2015

(hold the date 1/7/2015 ,, until you finish step 5

every time you restart your computer, check the date, if it is on 1/7/2015)

2- Install patch ( choice option 2 )

3- Make a backup of your windows system (I recommend, this is optional)

4- Open the program with the interface connected ,,( choose NON DEALER,when open program for first time ) , keep vcm2 turn on,on the computer.

5 – Create a restore point,,,then turn off vcm of the computer

6 – Okay, now install the new version, v109.01, before installing, changing the date of your computer, to the current day

7- After installing, go back to the restore point, which you created in step 5, activate this restore point, and then open the program

8- Finally, install FordExtendProgram (click right mouse button click on, run as administrator)

I have tried IDS V110 on 2011 Ranger/Mazda B series/Troller 2.2L

Its diagnostic is all ok.

ford-ids-110-mazda-768x432

Mega link:

https://mega.nz/#!ZOYGiSxT!_M02WlSt48iCvZimlK2a-V50vsZa5schHq3V5Zrrlsg
